Rocware RC90 4K PTZ Video Conference Camera

RC90 provides a flexible and wide range of applications through a single IP cable and transmits various video and audio signals with low latency to simplify the workflow. AI tracking is enable to subtly capture speakers based on their movements. With 20x optical zoom and 4K resolution, combined with AI tracking and smooth PTZ functions

RC90 uses a new generation of Sony 1 / 1.8 inches, up to 8.42 megapixel high-quality UHD CMOS sensors to achieve 4K (3840×2160) ultra-high resolution images. It delivers 4K of brilliant colors and detailed video at 60fps, even in environments that are too dark or too bright.

General Specification

Input Voltage DC 12V / PoE (802.3af)
Input Current 12V 1.0A (max.) / 5V 1.5A (max.)
Operating Temperature -10°C ~ 40°C
Storage Temperature -40°C ~ 60°C
Power Consumption 12W (Max)
Size 144mm x 144mm x 167.9mm

Network Features

Encode Protocol H.264/MJPEG
Video Stream First Stream, Second Stream
First Stream Resolution 3840×2160, 1920×1080, 1280×720,
1024×576,etc
Sub Stream Resolution 720×576, 720×480, 320×240, etc
Video Bit Rate 32Kbps ~ 20480Kbps
Bit Rate Type Variable bit rate，Fixed bit rate
Frame Rate 50Hz: 1fps ~ 50fps, 60Hz: 1fps ~ 60fps
Audio Compression AAC、G711A
Audio Bit Rate 96Kbps, 128Kbps
Support protocols NDI®|HX2, SRT, TCP/IP,HTTP,RTSP,
RTMP(s),Onvif,DHCP,Multicast,etc
