The New & Improved WLA-210XP is The Passive Variant
Key Features of WLA-210XP Line Array Loudspeaker
- Dual 10″ passive
- 138 dB Max SPL @ 1 meter
- 15 mm / 18 mm Birch plywood construction
- 100° x 10° dispersion
- 800 W LF + 90 W HF Continuous
- 1600 W LF + 180 W HF Programme
- 3200 W LF + 360 W HF Peak
WLA-210XP features custom phase plugs and the extraordinary Wharfedale Pro EVO-Fold waveguide. Combined, these lead to a huge reduction in the usual phase issues that traditional 2-way line arrays have due to them having the drive units physically some distance apart in the array.
The WLA-210XP system is supported with downloadable FIR presets for DP-F / N series amplifiers. FIR presets are also available for the SC-48 FIR Loudspeaker Management System for use with other amplifiers such as XR series or CPD series. For detailed system design WLA-210XP is also supported with downloadable. All files for Ease Focus.
The matching dual 15″ passive subwoofer (pictured), WLA-210XSUB, is the perfect partner for WLA-210XP. Meanwhile, the optional WLA-210X Common Fly Frame completes the system and allows for versatile system configurations of either subwoofer or array elements or both..
WLA-210XP has been designed and engineered in the UK and is targeted at the touring and fixed install sectors.
CLOSE up
Learn about the technical features of the WLA-210XP Line Array System
Specifications of the WLA 210XP Passive Line Array
| Model Name | WLA-210XP | WLA-210XSUB |
|---|---|---|
| System Type | Passive | Passive |
| Configuration | two-way | Dual 15” Subwoofer |
| Frequency Response (+/-3 dB) | 58-20 KHz | 39 Hz – 900 Hz |
| Frequency Range (-10 dB) | 50-20 KHz | 35 Hz -1.5 KHz |
| Sensitivity (2.83 v / 1 m) | 102 dB | 108 dB |
| Calculated Maximum SPL @1 m | 138 dB | 145 dB |
| System Rated Impedance | 8 Ω | 4 Ω |
| Low Frequency Transducer | ||
| Size | 260 mm / 10” | 2 x 381 mm / 2 x 15” |
| Voice Coil Size | 65 mm / 2.5” | 101.6 mm / 4” |
| Rated Impedance | 16 Ω X 2 (Parallel) | 8 Ω x 2 |
| LF Power (re:AES2-2012) | 2 x 400 W | 2 x 600 W |
| High Frequency Transducer | ||
| HF Driver Type | Compression Driver | |
| Voice Coil Size | 75 mm / 3” | |
| Exit Size | 1.4″ | |
| Diaphragm Material | Titanium | |
| Rated Impedance | 8 Ω | |
| HF Power (re:AES2-2012) | 90 W | |
| Nominal Coverage (H x V) | 100 H x 10 V EVO-Fold® | |
| Power | ||
| System Continuous Power | HF:90 W/LF:800 W | 1200 W |
| System Programme Power | HF:180 W/LF:1600 W | 2400 W |
| System Peak Power | HF:360 W/LF:3200 W | 4800 W |
| Crossover frequency | 1.5 KHz | – |
| Bi-Amp Mode Switch | Yes | |
| Input Connector | 2 x speakON | 2 x speakON |
| Hardware | 3 points Integral adjustable rigging 0°-10° |
Integral side plate non adjustable |
| Enclosure | ||
| Enclosure Material | 15 mm,18 mm plywood | 18 mm Plywood |
| Finish | TOUGH-TONE Paint | TOUGH-TONE Paint |
| Grille Material & Finish | steel | 1.2 mm Black Steel |
| Dimensions – (Unpacked) | ||
| Height Front | 314 mm / 12.4” | 485 mm / 19.1″ |
| Height Rear | 240.2 mm / 9.46” | 485 mm / 19.1″ |
| Width | 760 mm / 29.9” | 760 mm / 29.9″ |
| Depth | 504 mm / 19.84” | 716 mm / 28.2″ |
| Dimensions – (Packed) | ||
| Height | 404 mm / 15.9” | 575 mm / 22.6″ |
| Width Front | 855 mm / 33.7” | 850 mm / 33.5″ |
| Width Rear | 855 mm / 33.7” | 850 mm / 33.5″ |
| Depth | 594 mm / 23.4” | 806 mm / 31.7″ |
| Weight | ||
| Net Weight (kg / lbs) | 38.8 kg / 77.6 lbs | 63.0 kg / 138.4 lbs |
| Gross Weight (kg / lbs) | 41.3 kg / 90.9 lbs | 68.0 kg / 149.6 lbs |
